Home All Products 12.8V 100Ah 1.3kWh LiFePO4 Battery Pack with Built-in BMS for RVs
IP65 ABS Case 12 V 8 Ah Rechargeable Deep Cycle Lithium Battery
IP65 ABS Case 12 V 8 Ah Rechargeable Deep Cycle Lithium Battery
Back to products
High-Performance 12.8V 280Ah Lithium Battery with Transparent Housing
High-Performance 12.8V 280Ah Lithium Battery with Transparent Housing
EverExceed

12.8V 100Ah 1.3kWh LiFePO4 Battery Pack with Built-in BMS for RVs

SKU: 12.8V 100Ah 1.3kWh LiFePO4 Battery Pack with Built-in BMS for RVs Category: All Products Tags: 1.3kWh, 100Ah, 12.8V, battery, Built-in BMS, LiFePO4, Pack, RVs
Share:
  • Additional information
  • Description
Additional information
Brand

EverExceed

Customer Application

Airports

Customer Type

Airports

Description

EverExceed LDP Series Lithium Iron Phosphate (LiFePO4) batteries are perfect for RV applications, offering maintenance-free operation for a hassle-free experience. Inherently safe and lightweight, the batteries ensure consistent and reliable performance, allowing you to enjoy uninterrupted power and peace of mind during your RV adventures.

  • Brand:EverExceed
  • Model:LDP 12-100
  • Rated Voltage(V):12.8V
  • Rated Capacity(Ah):100Ah
  • Certificates:UN 38.3; UL2054; UL1642
  • OEM/ODM Service:Yes, customized service available
  • Usage:Solar / wind energy storage system, UPS backup power, Telecommunication, Electric vehicle, Medical equipment, Wheel chair, Sweeper, Solar street light, Toys etc.

12.8V 100Ah  1.3kWh LiFePO4 Battery Pack with Built-in BMS for RVs


Super safety LiFePO4 battery: EverExceed Group 24 12 V 100 Ah lithium battery size is only 10.24 x 6.69 x 8.35 inches, take grade A+ LiFePO4 cells with UL certificate to achieve higher energy density, more stable performance and excellent quality, ensuring super safety and reliability.

An built-in reliable Battery Management System (BMS) guarantees the safe operation during whole service life. The BMS is built with perfect automatic protection against over-voltage, over-current, over-discharge, over-temperature.

EverExceed lithium batteries allow you to use 100% of their capacity, regardless of the rate of discharge. It won’t slow you down when your journey involves countless miles or remote campgrounds.



Select The Appropriate LifeP04 Battery For Your Needs

It is recommended to use a lithium battery charger with a current of 10A DC/20A DC. 10A lithium battery charger requires 10 hours to fully charge the 12 V 100 Ah lifepo4 lithium battery, and 20 A lithium battery charger requires 5 hours to fully charge the 12 V 100 Ah battery. Maximum support 1C (100A) charging, less than 1.5 hours can be fully charged, can meet the requirements of fast charging.



Basic parameter
Nominal Voltage 12.8V
Nominal Capacity 100Ah
Energy 1280Wh
Series Connections 4 Units Max
Parallel Connections 4 Units Max
Protection Over voltage, low voltage, over current, high temperature, low temperature, short circuit
Bluetooth Optional
LCD Optional
Active Balancing Optional
Discharge Specifications
Maximum Continuous Discharge Current 100A
Peak Discharge Current 200A(5S)
Discharge Over-Current Protection 300-400A(Conventional BMS, Non-Settable) / 110A±10A(Bluetooth BMS settable)
Recommended Low Voltage Disconnect 11.2V(2.8vpc)
Discharge Under-Voltage Protection 8.8V(2.2±0.1vpc)
Charge Specifications
Maximum Continuous Charge Current 100A
Recommended Charge Current 50A
Recommended Charge Voltage 14.2V
BMS Charge Voltage Cut-Off 15.0V(3.75±0.05vpc)
Charging Method CC-CV
Temperature Specifications
Discharge Temperature -20℃~60℃(-4℉~140℉)
Charge Temperature 0℃~50℃(32℉~122℉)
Recommended Storage Temperature 10℃~35℃(50℉~95℉)
Mechanical Specifications
Dimensions (L x W x H) 328x172x220mm
Weight 11.5kg
Terminal Type M8(MC4, Anderson, Others)
Case Material ABS
Enclosure Protection (Waterpoof Rating) IP55(IP68 Optional)
