38.4V /48V Lithium Ion Battery for golf tour car
Additional information
Description
EverExceed LiFePO4 batteries are meticulously engineered to fulfill the power and energy demands of golf carts. It provides extended run times, quick charging, and a lighter weight compared to traditional lead-acid batteries, ensuring exceptional and efficient performance on the course.
- Brand:EverExceed
- Model:LDP 36-100, LDP48-50
- Rated Voltage(V):38.4V / 48V
- Rated Capacity(Ah):100Ah / 50Ah
- Certificates:UN 38.3; UL2054; UL1642
- OEM/ODM Service:Yes, customized service available
- Usage:Solar / wind energy storage system, UPS backup power, Telecommunication, Electric vehicle, Medical equipment, Wheel chair, Sweeper, Solar street light, Toys etc.
38.4V /48V Lithium Ion Battery for golf tour car
With their longer lifespan, lightweight design, fast charging capabilities, and eco-friendly attributes, EverExceed lithium batteries have become the preferred choice for powering golf carts on courses.
An built-in reliable Battery Management System (BMS) guarantees the safe operation during whole service life. The BMS is built with perfect automatic protection against over-voltage, over-current, over-discharge, over-temperature.
Check the battery data and operating status at any time through the mobile APP, set the battery parameters, and manage the battery more intelligently and conveniently.
The prolonged lifespan of a lithium battery equates to years of dependable service on the golf course without the trouble of regular battery replacements, giving golfers peace of mind and long-term cost savings.
| Basic parameter | LDP36-100 | LDP48-50 |
| Nominal Voltage | 38.4V | 48V |
| Nominal Capacity | 100Ah | 50Ah |
| Energy | 3840Wh | 2400Wh |
| Series Connections | NA | |
| Parallel Connections | 4 Units Max | |
| Protection | Over voltage, low voltage, over current, high temperature, low temperature, short circuit | |
| Bluetooth | Optional | |
| LCD | Optional | |
| Active Balancing | Optional | |
| Discharge Specifications | ||
| Maximum Continuous Discharge Current | 200A | 100A |
| Peak Discharge Current | 250A(5S) | 150A(5S) |
| Discharge Over-Current Protection | 600-800A(Conventional BMS, Non-Settable) / 200A±10A(Bluetooth BMS settable) | 300-400A(Conventional BMS, Non-Settable) / 100A±10A(Bluetooth BMS settable) |
| Recommended Low Voltage Disconnect | 33.6V(2.8vpc) | 42V(2.8vpc) |
| Discharge Under-Voltage Protection | 26.4V(2.2±0.1vpc) | 33V(2.2±0.1vpc) |
| Charge Specifications | ||
| Maximum Continuous Charge Current | 100A | 50A |
| Recommended Charge Current | 50A | 25A |
| Recommended Charge Voltage | 43.2V-43.8V | 54V-54.7V |
| BMS Charge Voltage Cut-Off | 45V(3.75±0.05vpc) | 56V(3.75±0.05vpc) |
| Charging Method | CC-CV | CC-CV |
| Temperature Specifications | ||
| Discharge Temperature | -20℃~60℃（-4℉~140℉） | |
| Charge Temperature | 0℃~50℃（32℉~122℉） | |
| Recommended Storage Temperature | 10℃~35℃（50℉~95℉ | |
| Mechanical Specifications | ||
| Dimensions (L x W x H) | 522x240x220mm | |
| Weight | 30.0kg | 24.0kg |
| Terminal Type | M8（MC4, Anderson, Others） | |
| Case Material | ABS | |
| Enclosure Protection (Waterproof Rating) | IP55(IP68 Optional) | |
