EverExceed LFP lithium battery telecom solution is mainly used for the backup purpose of telecommunication industry; its performance is in compliance with the requirements in the telecommunication standard, with the adoption of LiFePO4 battery structure packing by flexible plastic film or aluminum alloy rigid packaging, it can satisfy the higher and new requirements of the telecom sector for the communication backup batteries.
Reliable 51.2V 15kWh Lithium Battery Solution for Telecommunications
Key Features
The 280Ah LiFePO4 battery cells feature a large capacity and are made from Grade A LFP cells sourced from top suppliers, ensuring exceptional battery consistency and performance.
This system features a built-in smart BMS for 100% protection, supports Modbus via RS485, and allows SNMP/GPRS remote monitoring, ensuring 24-hour real-time oversight.
This system offers superior performance with a 100% capacity test, the ability to connect up to 15 sets in parallel, and an impressive cycle life of over 10,000 cycles.
This system prioritizes safety with an advanced gyroscope anti-theft function, broad compatibility with most rectifiers, and adherence to stringent standards, including EC62619, UN38.3, CE, and RoHS, ensuring reliable and secure operation.
Applications
Energy storage system / Solar application / Telecom application / Emergency lighting / Medical equipment
Nominal Characteristics | |||
Battery Model | EV48280-T(15S) | Battery Model | EV48280-T(16S) |
Nominal Voltage | 48V | Nominal Voltage | 51.2V |
Nominal Capacity | 280Ah | Nominal Capacity | 280Ah |
Nominal Energy | 13440Wh | Nominal Energy | 14336Wh |
Electrical Characteristics | |||
Recommended Boost Charging Voltage | 54±0.5V | Recommended Boost Charging Voltage | 57.6±0.5V |
Floating Float Charging Voltage | 54±0.5V | Floating Float Charging Voltage | 57.6±0.5V |
Recommended Charging Current | 60A | Recommended Charging Current | 60A |
Maximum Charging Current | 100A | Maximum Charging Current | 100A |
Maximum Discharging Current | 100A | Maximum Disharging Current | 100A |
Operating Conditions | |||
Cycle Life | ≥10000 Cycles@80% DOD@25℃ | Cycle Life | ≥10000 Cycles@80% DOD@25℃ |
Roundtrip Efficiency | ≥98% | Roundtrip Efficiency | ≥98% |
Operating Charge Temperature | 0℃ to +50℃ | Operating Charge Temperature | 0℃ to +50℃ |
Operating Discharge Temperature | -20℃ to +60℃ | Operating Discharge Temperature | -20℃ to +60℃ |
Storage Temperature | -20℃ to +60℃ | Storage Temperature | -20℃ to +60℃ |
Mechanical Characteristics | |||
Length x Width x Height | 483 x 720 x 227 mm | Length x Width x Height | 483 x 720 x 227 mm |
Weight | 104 Kg | Weight | 110 Kg |
Terminal | M6 | Terminal | M6 |
IP Rating | IP20 |
