Options

• Low radiation dose (from 0.25 μSv), allowing multiple inspections of one person within a year
• Use of A-EYE software – artificial intelligence system for automatic detection and classification of objects located inside and on the human body
• High quality and information content of the image
• High detection capacity
• High throughput
• Integration into existing infrastructure, integration with access control systems and databases
• A wide range of image processing algorithms (tools)
• Easy storage and transfer of the received information
• Modular design for quick installation on site

CONPASS DMS

CONPASS DMS can unite X-ray scanners from distant locations into one network keeping track of the total X-ray exposure dose for each inspected person even when the person undergoes a security screening in different locations. CONPASS DMS synchronizes the information: inspected people’s accounts, scan records, and X-ray images between all connected devices. It is a set of applications used to run X-ray people screening systems. The system allows operators to inspect people and view their accounts, perform a security screening, and view the obtained X-ray images

CONPASS DMS include at least three levels of controlled access including the following:

• An “Operator” level for making scan, creating and filing reports and saving images as required.
• A “Supervisor” level for supervisory staff to update subject information, create / update operators, review images and file data and monitor all operators’ activity and data collected
• An “Administrator” level to create/update/delete user group members with different levels of access, view audit logs, view images, save images to external drives and generate reports

Key features

• Superior high quality images: Smart HD images for increased penetration and resolution
• Fast scan acquisition time: Only 5 second scan acquisition time
• Contraband detection software: Patented advanced software aiding operators in detecting contraband
• Torso area inspection: Precise screening for items on or in the body within the central area – the most important screening zone for swallowed threats
• ANSI/HPS N43.17-2009: Fully compliant to ANSI standards
• Modular design: Easily installed and relocated

Technical Data

Scan settings
