PD240

PD240 Wide search area Hand Held Metal Detection set

  • Wide search area for faster and accurate screening operations
  • High immunity to floor rebars allows lower-body screening without Sensitivity Reduction
  • Uniform detection of magnetic and non-magnetic targets
  • Full digital design: consistent performance and calibration-free operations
  • Programmable sensitivity
  • Detection of radioactive substances and materials (option)

PD240

Availability will be confirmed on request.
Check Availability

Product Specifications

Alarm Modes Optical / acoustic / vibratory alarm modes
Applications Airports / public events / stadiums / sports arenas / conventions / schools / security checkpoints / loss prevention / multiple-lane screening
Battery Life 100+ hours with 2500 mAh NiMH batteries
Battery Life with Sleep Mode Up to 200 hours
Calibration Calibration-free digital operation
Charging Built-in fast battery charger when used with the HHDS docking station
Compliance NIJ 0602.02 compliant and conforms to the new NIJ 0602.03 standard
Connectivity USB connection for PC configuration and customization
Construction Robust design suitable for indoor and outdoor operation
Control Panel Fully customizable with optical/ acoustic and vibration alarm selection
Detection Capability Uniform detection of magnetic and non-magnetic metallic targets/ including stainless steel
Detection Performance High sensitivity with long detection range and excellent body-effect compensation
Detection Technology Fully digital metal detection with Digital Signal Processing (DSP)
Dimensions 430 mm × 80 mm × 40 mm
Ergonomic Design Offset hand grip keeps the operator's hand away from the sensitive detection area
Floor Compatibility Designed to operate close to metal-reinforced floors without significant reduction in sensitivity
Housing Grey shock-resistant technical polymers
Key Advantage Wide search area combined with high sensitivity/ long detection range and strong immunity to nearby metal structures
Low Battery Indicator Yes
Manufacturer CEIA
Metal Interference High immunity to external metal masses/ electromagnetic interference and mechanical disturbance
Operating Temperature -40°C to +70°C
Optional Accessories Belt holster / carry bag / cigarette-lighter charging cable / multi-detector charging stations / PC configuration kit
Power Supply 2 × AA NiMH rechargeable batteries
Product Name PD240 Hand Held Metal Detector
Product Type Wide Search Area Hand Held Metal Detector
Relative Humidity 0–98% non-condensing
Search Area Wide search area designed for faster and more accurate screening
Sensitivity 3 programmable sensitivity levels
Storage Temperature -40°C to +80°C
Weight 470 g including battery

PD240 Documents

PD240 Wide search area Hand Held Metal Detection set

  • Wide search area for faster and accurate screening operations
  • High immunity to floor rebars allows lower-body screening without Sensitivity Reduction
  • Uniform detection of magnetic and non-magnetic targets
  • Full digital design: consistent performance and calibration-free operations
  • Programmable sensitivity
  • Detection of radioactive substances and materials (option)
  • Elegant, robust and ergonomic
  • Indoor and outdoor operations

The PD240 features a wide detection area for faster and more accurate screening operations. The PD240 combines CEIA’s signature high reliability with advanced detection and operator signaling features, including a high immunity to floor rebars for lower body screening without sensitivity reduction. The PD240 offers full compliance with the latest NIJ security standards, indoor and outdoor use, as well as up to 100 hours of continuous operation on a single charge of its long life rechargeable batteries and embedded fast and reliable battery charger.

Advantages & benefits

  • Programmable Sensitivity
  • Long Detection Range
  • Extended Continuous Operation Time
  • Automatic Low Power Mode during Screening Pauses
  • Embedded Long Life Rechargeable Batteries are renewable energy and eliminate the Operation Cost of Alkaline Batteries
  • Embedded Fast and Reliable Battery Charger: no need for removal of batteries
  • Dedicated Docking Station acts as Table Stand and Mains connection for Battery Charge
  • Operator Functions can be standard or customized by the user through PC GUI and USB connection

Elegant, robust and ergonomic : The PD240 features a special ergonomic design consisting of an offset hand grip which ensures that the operator’s hand does not interfere with the sensitive detection area. Special care has gone into the mechanical design of the detector.
Absence of sharp edges or corners allows the detector to be passed smoothly over the inspected area without getting caught in buttons, buckles, folds or other parts of clothing.

Advanced control panel : The control panel with buttons and warning lights is made from high-thickness silicon guaranteeing a high degree of protection to make the PD240 suitable for indoor and outdoor use.

NIJ Standard 0602.02 compliant : The technical features of the detector comply with the NIJ standard 0602.02 and the new NIJ draft standard 0602.03. The PD240 has uniform sensitivity to magnetic and non-magnetic targets including those made of stainless steel. At the same time the detector offers excellent body-effect compensation and has high immunity to external disturbance from electromagnetic and mechanical sources.

Extended continuous operation time : The PD240 is powered by two AA-size NiMH batteries with a battery life of over 100 hours. A Low Power Mode is automatically activated during periods of inactivity, extending the battery life up to 200 hours. An internal circuit optimizes battery recharging which takes less than five hours.

Full digital design : The PD240 is fully digital. Electronic functions include an inspection field transmitter-receiver based on Digital Signal Processing (DSP) technology, a digital operator interface and external communications over the incorporated USB port. This design combined with a special printed antenna ensures top reliability and very high repeatability.

Sophisticated communication capabilities : The digital design of the new metal detector also enables the maximum flexibility in selecting how detection alarms are signalled. Users can keep the factory settings or connect the detector over its USB to a PC and then personalize the settings with a dedicated graphic interface.

The PD240 incorporates innovative technical solutions which make it possible to operate much closer to floors with steel reinforcement bars than was previously possible with conventional hand-held detectors. All this without any reduction in sensitivity.

Power Supply : 2x AA size NiMH, rechargeable batteries

Fully customizable control panel

  • Optical, acoustic and vibratory alarm modes
  • 3-level sensitivity selection buttons

Detection and operational functions : Customizable via HHMD Configuration tool

Battery

  • Battery life: 100 + hours (AA NiMH batteries 2500 mAh); up to 200 hours with automatic sleep mode
  • Low battery indicator
  • Built-in fast battery charger in combination with the HHDS Docking station

Operating temperature : -40°C to 70°C

Storage temperature : -40°C to 80°C

Relative humidity : 0 to 98% (without condensation)

Dimensions

  • 430 mm x 80 mm x 40 mm
  • HHDS Docking station: 175 mm x 115 mm x 85 mm
  • Carry Bag: 430 mm x 340 mm x 105 mm

Weight

  • With battery: 470 g
  • HHDS Docking station (with power adapter): 755 g
  • Carry Bag: 1,3 kg

Color

  • Light grey RAL 7040
  • Carry Bag: Green RAL 7013

Manufactured: In grey shock-resistant technical polymers

Compliance

  • Conforms to the NIJ 0602.02 and the new NIJ 0602.03 Standards for metal detection
  • Conforms to the international standards currently applicable for safety, EMC and to the applicable CE regulations

NATO stock number : 6665150114797
