XRC 180-180DV (200kV) X-ray Baggage Dual View Scanning Machine – Tunnel Size 180 x 180 cm
Downloads
Additional information
| Weight | 6800 kg |
|---|---|
| Brand | |
| Customer Application |
X-ray Baggage Scanning |
| Customer Type |
Airports ,Border Control ,Critical Infrastructures ,Customs ,Distribution Centers ,Government Building ,Logistic Hub ,Shipping Companies |
| Certification |
STAC ,TSA |
| Anode Voltage |
200kV |
Description
XRC 180-180DV (200kV) X-ray Baggage Dual View Scanning Machine – Tunnel Size 180 x 180 cm
Technical Specification:
TUNNEL SIZE: 1,820 mm x 1,810 mm
DIMENSIONS: 8,580 mm x 3,015 mm x 2,785 mm
APPROX. WEIGHT UNPACKED: ~6,800 kg
CONVEYOR HEIGHT: 385 mm
CONVEYOR LOAD CAPACITY: 3,000 kg Evenly Distributed
SYSTEM POWER: 110/220V AC ± 10% 50/60 Hz, 12amp max.
CONVEYOR SPEED: 0.20 m/sec. Forward or Reverse
STEEL PENETRATION: 50 mm guaranteed; 52 mm typical
WIRE RESOLUTION: 36 AWG guaranteed; 38 AWG typical
ANODE VOLTAGE: 200 kV, operating at 200 kV
TUBE CURRENT: 1.2 mA
BEAM DIRECTION: 1st Generator: Vertically downward | 2nd Generator: Horizontally sideward
ARTICLE SEPARATION: Low Z, Medium Z, High Z to 0.5 Z Accuracy
COOLING: Oil and forced air cooling
- TSA ACSTL certified
- Dual View
- Latest generation technology and practical use
- Organic and inorganic alarm
- Upgradable software based on Linux
- Multilanguage support
| Tunnel Size | :1820 mm (W) x 1810 mm (H) | |
| :71,65 in (W) x 71,26 in (H) | ||
| Dimensions | ||
| Length | :8580 mm (337,80 in) | |
| Height | :3015 mm (118,70 in) | |
| Width | :2785 mm (109,65 in) | |
| Approx. Weight Unpacked | : 6800 kg (14991 lbs) | |
180-180DV provides excellent performance thanks to its 200kV generator and manufactured with dual view (DV) technology. Thanks to its 2 generator sources, it provides high resolution and detailed imaging in horizontal and vertical angles. The visuals can be accessed with a single scan without the need to re-place the packages in a different orientation. Thus, hidden objects in the luggage are detected more easily and quickly.
The device itself facilitates the operators use thanks to the various image processing functions, hazard alarm, advanced computer technology and the best in class software. It provides exceptional ease in detecting threats such as cutting tools, explosives narcotics and minimizes the error rate. It offers unique image quality by showing the scanned organic, inorganic and mixed items in different colors thanks to its multi-diode structure and quality in imaging of scanned objects.
It is designed with the latest technology to scan medium and large packages on a pallet in detail and provides the ideal solution for locations where security screening is required in high security facilities such as freight companies, terminals, airports, customs and general cargo.
