LS17330 CNA 3.6V SAFT lithium battery – Non rechargeable – LS17330 CNA | LS 17330 CNA | LS17330CNA
LS17330 CNA Documents
| Battery Features | Non-rechargeable |
|---|---|
| Brand | SAFT |
| Capacity | 2.1 Ah |
| Cell Size | C |
| Leads | Axial |
| Current Rating | 3.67 V |
| Type of Battery | Lithium |
LS17330 CNA 3.6V SAFT lithium battery – Non rechargeable – LS17330 CNA | LS 17330 CNA | LS17330CNA
3.6 V Primary lithium-thionyl chloride (Li-SOCl2) High energy density – 2∕3 A-size bobbin cell
Benefits
- High voltage response, stable during most of the lifetime of the application
- Wide operating temperature range (- 60°C/+ 85°C)
- Low self-discharge rate (less than 1 % after 1 year of storage at + 20°C) E
- Easy integration into compact systems
- High voltage response, stable during most of the lifetime of the application
- Low self-discharge rate (less than 1 % per year of storage at +20°C)
- Ease of use
- Non-flammable electrolyte
- All cells are hermetically sealed in stainless steel cans (low magnetic signature and superior resistance to atmospheric corrosion)
- Wide operating temperature range (from -60°C to 85°)
- Long storage and operational life
Main applications
Primary Lithium Thionyl Chloride speciality size batteries are used in electronic devices that require a small, compact source of power. Example applications include:
- Utility metering
- Automatic meter reading
- Alarms and security devices
- Tollgate systems
- Memory back-up
- Tracking systems
- Automotive electronics
- Professional electronics
- Emergency Transmitters
- Measuring Instruments
- Real-Time Clocks
- Backup Systems
These are original SAFT batteries made in France with certificate of origin (COO). Only buy SAFT batteries from FPGT General Trading – Authorized Distributor for SAFT batteries – there are many counterfeit SAFT batteries in the market which are very difficult to identify sold on Amazon and which can damage your devices. We only sell SAFT direct to customers and through our FPGT Website “only”.
Specification
|
Manufacturer
|
SAFT | |
|
Type of battery
|
lithium | |
|
Cell size
|
2/3A, 17335 | |
|
Rated voltage For products in the Cables and Wires category, a digit/digit number indicates:
Rated volage U0/U where: U0 = cable nominal voltage between the conductor and the metal covering or earth U = cable nominal voltage between the phase conductors |
3.6V | |
|
Capacity
|
2.1Ah | |
|
Battery features
|
non-rechargeable | |
|
Body dimensions
|
16.5×33.4mm | |
|
Leads
|
Axial |
Lithium Thionyl Chloride Batteries
A 3.6V Primary Lithium Thionyl Chloride (Li-SOCl₂) from Saft. This battery is a non-standard sizes battery designed for reliability in specialist applications such as measuring devices, alarms and safety equipment, emergency transmitters, backup systems or real-time clocks. With an operating range from -60°C to 85°, C and resistance to wet environments are suitable to be used indoor and outdoor. They provide the high-performance and longer lasting life.
FAQ’s
Are Lithium Thionyl Chloride Batteries Harmful – Lithium Thionyl Chloride batteries can sometimes leak a substance called potassium hydroxide which is a caustic agent that can cause eye, skin and respiratory irritations. This risk is reduced by not mixing different manufacturer battery types, batteries of different chemistries and by the replacement of all batteries at the same time.
How to dispose of Lithium Thionyl Chloride Batteries – Recycle responsibly, a wide range of schemes are available.
Safety Advice
• Keep out of sight and reach of children.
• Fire, explosion and burn hazard – Do not recharge, short circuit, crush, disassemble, heat above 100ﾟC (212ﾟF), incinerate
• Due to the high terminal voltage (3.6V), they are not suitable as direct replacements for other battery technologies in the same can sizes.
Guidance:
• Always install the batteries correctly as per instruction
• Ensure that the contact points are clean and conductive
• Do not mix different types of battery
• Do not heat or attempt to recharge the battery
• Do not dispose of in a fire
Approvals
