Saft Lithium Thionyl Chloride 3.6V, 1/2 AA Battery – Saft LS14250 3.6V 1/2AA Lithium Battery, 3.6 Volt 1200mAh LS14250 | LS 14250 | SAFT LS 14250
| Brand | SAFT |
|---|---|
| Cell Size | 1/2 AA |
| Type of Battery | Lithium |
Saft Lithium Thionyl Chloride 3.6V, 1/2 AA Battery – Saft LS14250 3.6V 1/2AA Lithium Battery, 3.6 Volt 1200mAh
Authorized Distributor for MEA Region.
Lithium Thionyl Chloride Batteries
A 3.6V Primary Lithium Thionyl Chloride (Li-SOCl₂) from Saft. This battery is a non-standard sizes battery designed for reliability in specialist applications such as measuring devices, alarms and safety equipment, emergency transmitters, backup systems or real-time clocks. With an operating range from -60°C to 85°, C and resistance to wet environments are suitable to be used indoor and outdoor. They provide the high-performance and longer lasting life.
Features and benefits:
- High voltage response, stable during most of the lifetime of the application
- Low self-discharge rate (less than 1 % per year of storage at +20°C)
- Ease of use
- Non-flammable electrolyte
- All cells are hermetically sealed in stainless steel cans (low magnetic signature and superior resistance to atmospheric corrosion)
- Wide operating temperature range (from -60°C to 85°)
- Long storage and operational life
Typical Applications:
- Primary Lithium Thionyl Chloride speciality size batteries are used in electronic devices that require a small, compact source of power. Example applications include:
- Emergency Transmitters
- Alarms and Safety Equipment
- Measuring Instruments
- Real-Time Clocks
- Backup Systems
- Tracking Systems
- Automotive Electronics
- Professional Electronics
FAQ’s
- Are Lithium Thionyl Chloride Batteries Harmful? – Lithium Thionyl Chloride batteries can sometimes leak a substance called potassium hydroxide which is a caustic agent that can cause eye, skin and respiratory irritations. This risk is reduced by not mixing different manufacturer battery types, batteries of different chemistries and by the replacement of all batteries at the same time.
- How to dispose of Lithium Thionyl Chloride Batteries? -Recycle responsibly, a wide range of schemes are available.
Safety Advice
- Keep out of sight and reach of children.
- Fire, explosion and burn hazard – Do not recharge, short circuit, crush, disassemble, heat above 100ﾟC (212ﾟF), incinerate
- Due to the high terminal voltage (3.6V), they are not suitable as direct replacements for other battery technologies in the same can sizes.
Guidance:
- Always install the batteries correctly as per instruction
- Ensure that the contact points are clean and conductive
- Do not mix different types of battery
- Do not heat or attempt to recharge the battery
- Do not dispose of in a fire
Features:
- Brand: SAFT Batteries
- Made in: France
- Size: 1/2AA
- Nominal Voltage: 3.6V
- Chemistry: Lithium Thionyl Chloride
- Capacity: 1.2Ah
- Terminal: Standard
- Dimensions: 14.55 x 25.15mm
- Battery features: non rechargeable
- High voltage response, stable during most of the lifetime of the application
- Wide operating temperature range (-60°C/+85°C)
- Low self-discharge rate (less than 1 % per year of storage at +20°C)
- Easy integration into compact systems
- Superior resistance to atmospheric corrosion
- Low magnetic signature
- Stainless steel container and end caps for a low magnetic signature
- Hermetic glass-to-metal sealing
- Non-flammable electrolyte
- Non-restricted for transport/non-assigned to Class 9 accounting to the UN Recommendations on the transport of dangerous goods
- Underwriters Laboratories (UL) Component Recognition
- Compliant with IEC 60086-4 safety standard and IEC 60079-11 intrinsic safety standard (class T4 assignment)
The product, marked as LS 14250, is a battery made by SAFT. It is a lithium-type battery, which means that its main electrochemical component is lithium. The nominal voltage for this battery is 3.6V, indicating the maximum voltage it can provide when not under load. The cell size is 1/2AA, indicating the physical dimensions of the battery.
The capacity of this battery model is 1200mAh. Capacity in milliampere-hours is a measure of the amount of electrical energy the battery can deliver for a specified time.
It is a non-rechargeable battery, meaning it is not intended for multiple uses through cyclic charging and discharging. The external dimensions of the battery are Ø14.5x25mm, indicating its diameter and height.
The product does not have leads, meaning it does not have additional wires for connecting to a device. It is necessary to directly place the battery in the device’s battery slot
Works Great With:
- Utility metering
- Automatic meter reading
- Alarms and security devices
- Tollgate systems
- Memory back-up
- Computer real-time clocks
- Tracking systems
- Automotive electronics
- Professional electronics
Shelf Life
Saft lithium-thionyl chloride batteries have a low self-discharge rate of less than 1% per year in storage at +20°C). The storage area should be clean, cool, dry and ventilated.
Transportation
Please refer to the Battery Information Sheet / Material Safety Data sheet. Batteries are ARTICLES according to REACH and OSHA and are not required to produce an MSDS.
Warnings
Fire, explosion and burn hazard. Do not recharge, short circuit, crush, disassemble, heat above 100°C (212°F), incinerate, or expose contents to water. Do not solder directly to the cell (use tabbed cell versions instead).
- Cell Size : 1/2AA
- Voltage : 3.6
- Capacity : 1.20Ah
- Cell Construction : Bobbin
- Pulse Capability : Typically up to 100mA
- Max Continuous Current : 35mA
- Max Pulse Discharge Rate : 0.1A
- Dimensions : 14.55×25.15mm (0.57×0.99in)
- Weight : 8.9g (0.3oz)
- Lithium Metal Content : approx. 0.3g
- Termination : Flat Contact (button-top)
- Operating Temperature : -60°C to 85°C (-76°F to 185°F)
- Storage Temperature : +30°C (+86°F) max
